A worked mechanism
Count the population that pays each penalty.
Use the chapter’s fixed 1,000-instruction workload. Penalties are additive here; overlapping stalls are intentionally excluded.
Base execution
1,000 cycles
One base cycle for every instruction.
Branch recovery
150 cycles
250 branches × 20% misses × 3 extra cycles.
Load-use interlock
60 cycles
200 loads × 30% adjacent consumers × 1 extra cycle.
Measured denominator
CPI = 1.21
1,210 total cycles divided by the same 1,000 instructions.
Work it through
From events to execution time
At 2.5 GHz, 1,210 cycles take 484 ns. 1,000 instructions / 484 ns gives approximately 2,066 million instructions per second.
The 20% branch miss rate applies to branches, not to all instructions.
Watch for this
Using 20% of every instruction for branch recovery overcounts this fixture by four times.
Check your reasoning
Keep instruction-class counts, conditional event counts, extra cycles, and clock period in the same measurement window.
Worked problems
Carry the probability through the hierarchy.
State the timing convention, convert percentages to probabilities, and multiply a penalty only by the fraction of instructions or accesses that actually pay it.
AMAT calculator
Price every miss at the level where it occurs.
AMAT = tL1 + mL1 × (tL2 + mL2 × tDRAM)2 + 0.1 × (10 + 0.2 × 60)
4.2 nsAMAT is 4.2 ns. L1 contributes 2 ns, L2 contributes 1 ns, and DRAM contributes 1.2 ns. L1 lookup is the largest contribution.
Pipeline CPI and MIPS
CPI = 1 + 0.25(0.20)(3) + 0.20(0.30)(1)Branch misses add 0.15 CPI. Load-use stalls add 0.06 CPI.
CPI = 1.21MIPS = 2,500 MHz / 1.21 = 2,066.12Three-level AMAT tradeoff
2 + 0.10(10 + 0.20 × 60) = 4.2 nsWith the proposed slower but higher-hit L2:
2 + 0.10(12 + 0.05 × 60) = 3.5 nsThe proposal improves AMAT by 0.7 ns, or 16.7%.1 MiB, 8-way, 64-byte PIPT tag array
lines = 2²⁰ / 2⁶ = 2¹⁴
sets = 2¹⁴ / 2³ = 2¹¹
offset = 6 bits · index = 11 bitsFor the source's implied 34-bit physical address, tag = 34 − 11 − 6 = 17 bits. Including one valid bit per line:
(17 + 1) × 2¹⁴ = 294,912 bits288 Kibit = 36 KiBWrite-back L1, write-through L2 CPI
memory-op fraction = 0.20 + 0.10 = 0.30expected data time = 0.30 × [2 + 0.10(15 + 0.20×70 + 0.40×15)] = 1.65 ns/instructionThe prompt supplies nanoseconds but no processor clock period, so a unique CPI cannot be derived. For clock period T in ns:
CPI = 1 + 1.65 / TAt T = 1 ns, CPI = 2.65. If the base pipeline already includes the 2 ns L1 hit, count only miss overhead: CPI = 1 + 1.05/T, or 2.05 at T = 1 ns.Four-level page-table EMAT
The translated 48-bit virtual address splits into four nine-bit indexes and a 12-bit offset. A 40-bit physical address has a 28-bit PPN plus that offset. Eight-byte PTEs make each 512-entry page-table level exactly 4 KiB.
translation = 1 + 0.01(4 × 100) = 5 cyclesdata access = 1 + 0.05(100) = 6 cyclesA TLB miss pays four uncached PTE reads. The subsequent L1 lookup still occurs, and an L1 miss pays one DRAM access. This exercise uses the source's serial TLB-then-cache timing model; a VIPT implementation may overlap part of those hit paths.
EMAT = 5 + 6 = 11 cyclesPut it into practice
Explain the mechanism. Test your reasoning.
Use the experiment above to support your answer, then apply the idea in the question bank.
