Q103FreeDesign Verification
Verify unique zero-sum triplets
Interview prompt
Question
Complete the supplied checker for an accelerator that streams every unique sorted three-value combination whose widened sum is zero, in strict dictionary order. Parameters satisfy N=1..12 and W=1..32, defaulting to 12 each. The four-bit count may be invalid; active values are signed W-bit numbers and duplicate inputs are allowed. Observe signals immediately before updates at each rising edge; rst_n is known at every sampled edge. Known request fields are snapshotted on req_valid && req_ready, after at least one sampled reset. Inputs may then change. An output cannot belong to a request accepted on that same edge. rst_n=0 is a sampled cancellation of all checker and device work.
